Front Serviece COB Display With High Environmental Tolerance Rate and Lightweight Cabinet

Name: Front Serviece COB Display With High Environmental Tolerance Rate and Lightweight Cabinet
Brand: Visual World
Price: 1 USD

Buy cheap Front Serviece COB Display With High Environmental Tolerance Rate and Lightweight Cabinet product

Brand Name : Visual World

Model Number : COB P0.9 P1.9 P1.25 P1.56

Certification : EMC,CE,FCC,ROHS

Place of Origin : China

MOQ : Negotiatble

Price : Negotiatble

Payment Terms : T/T

Supply Ability : 5000 sqm/month

Delivery Time : 12 work days

Packaging Details : Plywood case, export carton box

Product Name : COB Small Pixel Pitch Indoor Display With Ultra Thin Cabinet For Multiple Usage In Both Outside and Inside

Brightness : 0-2000nits

Maintaince : Front Serviece

Cabinet Weight : 4.6kg

Cabinet Material : Die-casting Aliuminum

Pixel Pitch : P0.9 P1.9 P1.25 P1.56

Cabinet Dimension : 600x337.5mm

Warranty Time : 2 years

IP Rate : IP 65

Gray Scale : 16 Bit

Installation : Mounting Hanging Stacking

Operational Humidity : 10%-90%RH

Operational Temp : -20°C~+50°C

Viewing Angle : H:170°, V:170°

Contact Now

COB Display With High Environmental Tolerance Rate and Multiple Installation Method

Product Description:

Our COB Display combines durability with exceptional image quality, built to withstand dust, moisture, and temperature extremes for reliable indoor and outdoor use. With multiple installation options—wall-mounting, ceiling suspension, or freestanding—this display adapts to any environment, making it ideal for high-traffic areas, retail, events, and more.

Features:

Product Features: COB Small Pixel Pitch Indoor Display With Ultra-Thin Cabinet
Compact Dimensions: Cabinet size of 600 x 337.5 mm for flexible and space-efficient installation.
Temperature Range: Operates in temperatures from -20°C to +50°C, making it adaptable to various environments.
Wide Viewing Angle: Offers a 170° horizontal and vertical viewing angle for optimal visibility from multiple perspectives.

Technical Parameters:

Model	P0.7	P0.9	P1.25	P1.56
Pixel Pitch	0.7mm	0.9mm	1.25mm	1.56mm
LED Type	COB	COB	COB	COB
Cabinet Dimensions	600337.535mm	600337.535mm	600337.535mm	600337.535mm
Module Size	150x168.75mm	150x168.75mm	150x168.75mm	150x168.75mm
Cabinet Weight	4.6kg	4.6kg	4.6kg	4.6kg
Cabinet Material	Die-casting Aluminum	Die-casting Aluminum	Die-casting Aluminum	Die-casting Aluminum
Driving Type	1/36	1/36	1/27	1/48
Maintenance	Front service	Front service	Front service	Front service
Brightness	0-2000 nits	0-2000 nits	1500 nits	1000 nits
Max/Avg Power	390/136 W/m²	420/147 W/m²	330/100 W/m²	330/100 W/m²
IP Rating	Front: IP65 Rear: IP30	Front: IP65 Rear: IP30	Front: IP65 Rear: IP30	Front: IP65 Rear: IP30
Refresh Rate	>3840Hz	>3840Hz	>3840Hz	>3840Hz
Installation Type	Mounting, Hanging, Stacking	Mounting, Hanging, Stacking	Mounting, Hanging, Stacking	Mounting, Hanging, Stacking
Gray Scale	16bit	16bit	16bit	16bit
Viewing Angle	H:170°, V:170°	H:170°, V:170°	H:170°, V:170°	H:170°, V:170°
Operational Temp	-20°C~+50°C	-20°C~+50°C	-20°C~+50°C	-20°C~+50°C
Operational Humidity	10%-90%RH	10%-90%RH	10%-90%RH	10%-90%RH
